GigaWave Optical Passives

ATX’s GigaWave® portfolio includes a variety of Optical Passives to complement the company’s digital optical transport and amplifier solutions. These field-hardened, low-insertion loss filters are designed for use in indoor and outdoor environments and provide flexible options for multiwavelength applications. The expanded family of GigaWave Optical Passives offers a variety of form factors, such as rackmount LGX modules, cassettes, tubes and FOSC trays, and includes channel counts up to 48 with a wide range of options that include multiplexers, demultiplexers, add-drop filters, band combiners as well as red/blue filters for combining or separating different groups of channels. All GigaWave Optical Passives meet Telcordia GR standards, providing excellent environmental and mechanical stability.

Request Info How To Buy

Data Sheet: GigaWave Optical Passive Modules

Benefits

Supports FTTH & Distributed Access Architecture (DAA) – Enables reliable and fiber-efficient Remote PHY (R-PHY)-based node deployments. Applicable for PON Remote-OLT applications.
Optimizes Fiber Utilization – Combines or splits up to 48 DWDM channels within 100GHz spacing into/from single fibers.
Facilitates Add/Drop Operations – Enables the selective drop off of wavelengths along an optical route without the need or expense of converting every wavelength in the fiber to an electric signal.

Features

Low Insertion loss
Flat top filter spectral shape
Express/upgrade and monitor ports
Field hardened
Variety of form factors
Fully passive, no power supply or cooling

GigaXtend GS7 1.8GHz Node

Distributed Access Architecture (DAA)

The 2050 Project

MUX/DEMUX (20CH, 40CH, 48CH) MUX/DEMUX (4CH, 8CH) Add/Drop (2CH, 4CH) Band Combiners Filters Ordering Information Documentation

GigaWave Optical Passives, 20/40/48-Channel
Multiplexer/Demultiplexer

ATX offers multiplexers/demultiplexers, on consecutive 100GHz ITU grid in dual- or triple-width LGX boxes and
in Cassettes.

The modules have an Express port for outside DWDM band, as well as an OTDR port to provide an option for live OTDR traces without disrupting traffic. Test downstream and upstream ports offer capability to monitor transmitted and received signals.

Features

Low Insertion loss
Flat top filters on 100GHz spacing
Express and monitor/test ports
Field hardened
Variety of form factors
Fully passive, no power supply or cooling

		20CH: GW-OP-MDM20-xx-yy-LGX2/GW-OP-MDM20-xx-yy-CNN 40CH: GW-OP-MDM40-LGX2/GW-OP-MDM40-CNN 48CH: GW-OP-MDM48-LGX3/GW-OP-MDM48-CNN
OPTICAL		GW-OP-MDM20-20-39-LGX2/CNN	GW-OP-MDM20-40-59-LGX2/CNN	GW-OP-MDM40-LGX2/CNN	GW-OP-MDM48-LGX3/CNN
DWDM PORTS	OPERATING ITU CHANNELS	ITU CH 20-CH39, 1561.42-1546.12nm	ITU CH 40-CH59, 1545.32-1530.33nm	ITU CH 20- 59, 1561.41 – 1530.33nm	ITU CH 16-63, 1564.66-1527.22nm
	OPERATING ITU DWDM FREQUENCY	192.0-193.9 THz	194.0-195.9 THz	192.0-195.9 THz	191.6 THz
	CHANNEL SPACING	100GHz
	PASSBAND at 0.5dB	± 0.125 nm
	CHANNEL INSERTION LOSS	≤ 4.0 dB		4.5 dB	≤ 4.0 dB
	DWDM UNIFORMITY	≤ 4.0 dB
	RIPPLE	≤ 0.5 dB
	ADJACENT CHANNEL ISOLATION	≥ 30 dB
	NON-ADJACENT CHANNEL ISOLATION	≥ 45 dB
	DWDM PORT DIRECTIVITY	≥ 45 dB
TEST PORTS	INSERTION LOSS – DWDM PORT TO TEST PORT	≤ 27 dB
	INSERTION LOSS – COM to Rx PORT	≤ 22 dB
EXPRESS PORT	EXPRESS PORT WAVELENGTH	1260-1520nm and 1570-1620nm
	EXPRESS PORT INSERTION LOSS	≤ 1.5 dB
	EXPRESS PORT CHANNEL ISOLATION	≥ 12 dB
UPGRADE PORT	WAVELENGTH	1527.22 – 1564.68 nm Excluding Used Channels
	INSERTION LOSS	≤ 3.5 dB
OTDR PORT	OTDR PORT WAVELENGTH	1640-1660 nm
	OTDR PORT INSERTION LOSS	≤ 2.0 dB
ALL PORTS	PDL	≤ 0.25 dB
	PMD	≤ 0.25 dB
	OPTICAL RETURN LOSS	≥ 45 dB
	OPTICAL POWER HANDLING	300 mW
ENVIRONMENTAL
OPERATING TEMPERATURE		-40°C to +85°C (-40°F to +185°F)
OPERATING RELATIVE HUMIDITY		5-95% non-condensing
STORAGE TEMPERATURE		-40°C to 85°C (-40°F to +185°F)
STORAGE RELATIVE HUMIDITY		5-95% non-condensing
MECHANICAL
PACKAGING		20/40 CH LGX2: Dual Slot LGX, LC/APC Approximate 156 mm x 129.2 mm x 57.3 mm 48 CH LGX3: Triple Slot LGX, LC/APC Approximate 156 mm x 129.2 mm x 87 mm 20/40 CH MDM FALA: SC/APC (Test ports) Approximate 75 mm x 85 mm x 8.5 mm 48 CH MDM FALA: SC/APC (Test ports) Approximate 220 mm x 94 mm x 10.3 mm
FRONT FEATURES		DWDM Ports, 1x Common port, OTDR port, EXP Port, 2x Test Ports, 1x upgrade port
ALL PORTS		LC/APC
PORT TENSILE STRENGTH		> 5 N
RELIABILITY		GR1221 (if applicable) GR1209 (if applicable) GR326 (if applicable)

GigaWave Optical Passives, 4- or 8-Channel Multiplexer/Demultiplexer

ATX offers 4 and 8-channel multiplexers/demultiplexers, combining or separating 4 or 8 consecutive ITU channels on 100GHz grid in cassette form factor.

The 4-Channel Mux-DeMux GW-OP-MDM4-xx-yy covers the range of ITU CH 20-23, then CH56-59.
The 8-Channel Mux-DeMux GW-OP-MDM8-xx-yy covers the range of ITU CH20-27, then CH52-59.

The modules have an Express port for outside the DWDM band, as well as an UPGRADE port, which passes DWDM channels outside of 4 or 8 channels and is used to cascade the DWDM channels.

Features

Low Insertion loss
Flat-top filters
Express and monitor/test ports
Field hardened
Variety of form factors
Fully passive, no power supply or cooling

		GW-OP-MDM4-xx-yy-CLA GW-OP-MDM8-xx-yy-CLA
OPTICAL		GW-OP-MDM4-20-23-CLA	GW-OP-MDM4-56-59-CLA	GW-OP-MDM8-20-27-CLA	GW-OP-MDM8-52-59-CLA
DWDM PORTS	OPERATING RANGE OF CHANNELS	ITU CH 20-23, 1561.41 -1558.98 nm	ITU CH 56-59, 1532.68-1530.33 nm	ITU CH20-27, 1561.41-1555.75 nm	ITU CH52-59, 1535.82-1530.33 nm
	OPERATING ITU DWDM FREQUENCY RANGE	192.0-192.3 THz	195.6-195.9 THz	192.0-192.7 THz	195.2-195.9 THz
	CHANNEL SPACING	100GHz
	PASSBAND at 0.5 dB	± 0.125 nm
	INSERTION LOSS – DWDM PORTS TO OUT PORT	≤ 2.5 dB		≤ 3.0 dB
	DWDM UNIFORMITY	≤ 2.0 dB
	RIPPLE	≤ 0.5 dB
	ADJACENT CHANNEL to CHANNEL ISOLATION	≥ 30 dB
	NON-ADJACENT CHANNEL to CHNNEL ISOLATION	≥ 45 dB
	DWDM PORT DIRECTIVITY	≥ 45 dB
TEST PORTS	INSERTION LOSS – CHANNEL PORTS to Tx PORT	19-27 dB
	INSERTION LOSS – COM to Rx PORT	19-22 dB
EXPRESS PORT	EXPRESS PORT WAVELENGTH	1260-1520nm, 1570-1635nm
	EXPRESS PORT INSERTION LOSS	≤ 1.5 dB
	EXPRESS PORT CHANNEL ISOLATION	≥ 12 dB
UPGRADE PORT	WAVELENGTH	1527.22 – 1564.68 nm (Excluding Used Channels)
	INSERTION LOSS	≤ 3.0 dB
ALL PORTS	PDL	≤ 0.25 dB
	PMD	≤ 0.25 dB
	OPTICAL RETURN LOSS	≥ 45 dB
	OPTICAL POWER HANDLING	≤ 300 mW
ENVIRONMENTAL
OPERATING TEMPERATURE		-40°C to +85°C (-40°F to +185°F)
OPERATING RELATIVE HUMIDITY		5-95% non-condensing
STORAGE TEMPERATURE		-40°C to 85°C (-40°F to +185°F)
STORAGE RELATIVE HUMIDITY		5-95% non-condensing
MECHANICAL
PACKAGING		4CH MDM : 89 mm x 51 mm x 8 mm 8CH MDM : 96 mm x 78 mm x 8 mm CLA : Cassette
FEATURES		4 or 8 DWDM Ports, 1x Common port, UPG port, EXP Port, 2x Test Ports
ALL PORTS		SMF-28, 900um jacket, 1m fiber length LC/APC connectors
PORT TENSILE STRENGTH		> 5 N
RELIABILITY		GR1221 (if applicable) GR1209 (if applicable) GR326 (if applicable)

GigaWave Optical Passives, 2- or 4-Channel Optical

ATX offers 2- and 4-channel DWDM optical add/drop modules to add or drop one or more new wavelength channels to an existing multiwavelength WDM signal, and to drop one or more channels passing those signals to another network path. ATX offers these modules both in LGX or F-cassette housings.

Features

Low Insertion loss
Flat-top filters
Express and monitor/test ports
Field hardened
Variety of form factors
Fully passive, no power supply or cooling

		GW-OP-OADM2-xx-yy-L/F GW-OP-OADM4-ww-xx-yy-zz-L/F
OPTICAL		GW-OP-OADM2-51-27-L	GW-OP-OADM2-51-27-F	GW-OP-OADM2-52-28-L	GW-OP-OADM2-52-28-F	GW-OP-OADM4-51-52-27-28-F		GW-OP-OADM4-61-62-35-36-F
DWDM PORTS	OPERATING RANGE OF CHANNELS	ITU CH 51 & 27; 1536.61 & 1555.75 nm		ITU CH 52 & 28; 1535.82 & 1554.94 nm		ITU CH 51, 52, 27 & 28; 1531.90, 1535.82, 1555.75 & 1554.94 nm		ITU CH 61, 62, 35 & 36; 1528.77, 1527.99, 1549.32 & 1548.51 nm
	OPERATING ITU DWDM FREQUENCY RANGE	195.1 & 192.7 THz		195.2 & 192.8 THz		195.7, 195.2, 192.7 & 192.8 THz		196.1, 196.2, 193.5 & 193.6 THz
	CHANNEL SPACING	100GHz
	CHANNEL PASSBAND at 0.5 dB	± 0.125 nm
	INSERTION LOSS IN to DROP	≤ 1.5 dB					≤ 2.0 dB
	INSERTION LOSS ADD to OUT	≤ 1.5 dB					≤ 2.0 dB
	INSERTION LOSS IN to OUT	≤ 1.5 dB					≤ 2.0 dB
	ADJACENT CHANNEL ISOLATION IN to DROP	≥ 28 dB
TEST PORTS	ADJACENT CHANNEL ISOLATION ADD to OUT	≥ 28 dB
	NON-ADJACENT CHANNEL ISOLATION IN to DROP	≥ 45 dB
EXPRESS PORT	NON-ADJACENT CHANNEL ISOLATION ADD to OUT	≥ 45 dB
	PDL	≤ 0.25 dB
ALL PORTS	DIRECTIVITY	≥ 45 dB
	OPTICAL RETURN LOSS	≥ 45 dB
	OPTICAL POWER HANDLING	≤ 300 mW
ENVIRONMENTAL
OPERATING TEMPERATURE	20°C to +65°C (-4°F to +149°F)
OPERATING RELATIVE HUMIDITY	5-95% non-condensing
STORAGE TEMPERATURE	-40°C to +85°C (-40°F to +185°F)
STORAGE RELATIVE HUMIDITY	5-95% non-condensing
OPTICAL POWER HANDLING	300 mW
MECHANICAL
PACKAGING	2CH OADM – LGX box : 156 mm x 129.2 mm x 29 mm
	2/4CH OADM – F cassette: 96 mm x 78 mm x 8 mm
FEATURES	2 CH: 2 Add & 2 Drop Ports, 1 In and 1 Out 4 CH: 4 Add & 4 Drop Ports, 1 In and 1 Out
ALL PORTS	SMF-28, 900um jacket, 1m fiber length LC/APC connectors
PORT TENSILE STRENGTH	> 5 N
RELIABILITY	GR1221 (if applicable) GR1209 (if applicable) GR326 (if applicable)

GigaWave Optical Passives, 1×5 or 1×10 Ports Band Multiplexer/Demultiplexer

ATX offers 5- and 10-port Bandpass multiplexers covering ITU Channels 20-59. The 5-port version has 8 contiguous wavelengths per port while the 10-port model has only 4. Express port is included for all wavelengths outside ITU20-59. Monitor ports are also included on the common port.

Features

Low Insertion loss
Flat-top filters
Express and monitor/test ports
Field hardened
Fully passive, no power supply or cooling

		GW-OP-BMDM5-xx-yy-FALA GW-OP-BMDM10-xx-yy-FALA
OPTICAL		GW-OP-BMDM5-20-59-FALA	GW-OP-BMDM10-20-59-FALA
DWDM PORTS	OPERATING RANGE OF CHANNELS	ITU CH 20-59, 1561.41-1530.33 nm
	OPERATING ITU DWDM FREQUENCY RANGE	192.0-195.9 THz
	BAND SPACING	800 GHz		400 GHz
	CHANNEL PASSBAND	≥ 5.89 nm (CH20-CH27) ≥ 5.84 nm (CH28-CH35) ≥ 5.79 nm (CH36-CH43) ≥ 5.75 nm (CH44-CH51) ≥ 5.70 nm (CH52-CH59)		≥ 2.65 nm (CH20-CH23) ≥ 2.64 nm (CH24-CH27) ≥ 2.63 nm (CH28-CH31) ≥ 2.62 nm (CH32-CH35) ≥ 2.61 nm (CH36-CH39) ≥ 2.60 nm (CH40-CH43) ≥ 2.59 nm (CH44-CH47) ≥ 2.58 nm (CH48-CH51) ≥ 2.57 nm (CH52-CH55) ≥ 2.56 nm (CH56-CH59)
	CHANNEL INSERTION LOSS	≤ 3.2 dB		≤ 4.2 dB
	IL RIPPLE (for BWDM CHANNELS)	≤ 0.5 dB
	ISOLATION	≥ 15 dB (Adjacent) ≥ 35 dB (Non-adjacent)
	DIRECTIVITY	≥ 45 dB
TEST PORTS	INSERTION LOSS – BAND PORTS to Tx PORT	19–27 dB
	INSERTION LOSS – COM to Rx PORT	19–22 dB
EXPRESS PORT	EXPRESS PORT WAVELENGTH	1260-1520nm, 1570-1635nm
	EXPRESS PORT INSERTION LOSS	≤ 1.5 dB
	EXPRESS PORT ISOLATION	≥ 12 dB
ALL PORTS	PDL	≤ 0.25 dB
	PMD	≤ 0.25 dB
	OPTICAL RETURN LOSS	≥ 45 dB
	OPTICAL POWER HANDLING	300 mW
ENVIRONMENTAL
OPERATING TEMPERATURE		20°C to +65°C (-4°F to +149°F)
OPERATING RELATIVE HUMIDITY		5-95% non-condensing
STORAGE TEMPERATURE		-40°C to +85°C (-40°F to +185°F)
STORAGE RELATIVE HUMIDITY		5-95% non-condensing
MECHANICAL
PACKAGING		FOSC A tray: 227.5 mm x 98 mm x 11.6 mm
FEATURES		5 or 10 Band Ports, 1x Common port, 1x EXP Port, 2x Test Ports
ALL PORTS		SMF-28, 900um jacket, 1m fiber length LC/APC connectors
PORT TENSILE STRENGTH		> 5 N
RELIABILITY		GR1221 (if applicable) GR1209 (if applicable) GR326 (if applicable)

GigaWave Optical Passives, – Red/Blue OTDR Filter

ATX offers OTDR and Red/Blue filters in tube form factor. The Red/Blue filters are used to separate or combine Red band and Blue band wavelength signals in C band.

Features

Low Insertion loss
Field hardened
Fully passive, no power supply or cooling

	GW-OP-xx-SA/LA
OPTICAL	GW-OP-RB-SA	GW-OP-OTDR-LA
OPERATING RANGE OF CHANNELS	Red ITU CH 18-37, 1563.05-1547.72 nm Blue ITU CH 42-61, 1543.73-1528.77 nm	Passband: 1620 – 1670 nm Reflection Band: 1260 – 1604 nm
PASSBAND INSERTION LOSS	1.0 dB
REFLECTION INSERTION LOSS	1.0 dB
PASSBAND ISOLATION	14 dB	30 dB
REFLECTION ISOLATION	12 dB
PDL	0.3 dB
RETURN LOSS	45 dB
DIRECTIVITY	50 dB	45 dB
RIPPPLE	0.5 dB
OPTICAL POWER HANDLING	300 mW
ENVIRONMENTAL
OPERATING TEMPERATURE	-40°C to +85°C (-40°F to +185°F)
OPERATING RELATIVE HUMIDITY	5-95% non-condensing
STORAGE TEMPERATURE	-40°C to +85°C (-40°F to +185°F)
STORAGE RELATIVE HUMIDITY	5-95% non-condensing
MECHANICAL
PACKAGING	Tube : 40 x 5.5 mm
FEATURES	1x Common port, 1 x Reflect Red port. 1 x Pass Blue port	1x Common port, 1 x Reflect port. 1 x Pass port
ALL PORTS	1m fiber length SC/APC (R/B filter) connectors 1m fiber length LC/APC (OTDR filter) connectors
PORT TENSILE STRENGTH	> 5 N
RELIABILITY	GR1221 (if applicable) GR1209 (if applicable) GR326 (if applicable)

Part Number	Description
GW-OP-MDM48-LGX3-LA	Gigawave thin-Film 48-Ch channel (ITU Ch 16-63), 100Ghz DWDM Mux in Triple-wide LGX box(3RU), with EXP 1260-1520nm + 1570-1620nm and OTDR port (1640-1660nm), two Test Points (TX), SMF28 Ultra fiber, LC/APC for all channel ports.
GW-OP-MDM48-CNN	GigaWave Optical Passive Mux DeMux module, 48 Channels, 100GHz spaced, Starting ITU Channel 16, end ITU Channel 63, with OTDR port, Express port, Tx and Rx monitoring ports, in F cassette with SC/APC connectors (Test Ports Only)
GW-OP-MDM40-LGX2-LA	Gigawave 40 Channel (ITU CH20-59) 100GHz DWDM Mux in Double wide LGX box, Upgrade port, OTDR, two Test Points, LC/APC
GW-OP-MDM40-CNN	Gigawave Optical Passive Mux DeMux module, 40 Channels, 100GHz spaced, Starting ITU Channel 20, end ITU Channel 59, with OTDR port, Express port, Tx and Rx monitoring ports, in F cassette with SC/APC connectors (Test Ports Only)
GW-OP-MDM20-20-39-LGX2-LA	Gigawave 20 Channel (ITU CH20-39) 100GHz DWDM Mux in Double wide LGX box, Upgrade port, OTDR, two Test Points, LC/APC
GW-OP-MDM20-40-59-LGX2-LA	Gigawave 20 Channel (ITU CH40-59) 100GHz DWDM Mux in Double wide LGX box, Upgrade port, OTDR, two Test Points, LC/APC
GW-OP-MDM20-20-39-CNN	Gigawave Optical Passive Mux DeMux module, 20 Channels, 100GHz spaced, Starting ITU Channel 20, end ITU Channel 39, with OTDR port, Express port, Tx and Rx monitoring ports, in F cassette with SC/APC connectors (Test Ports Only).
GW-OP-MDM20-40-59-CNN	Gigawave Optical Passive Mux DeMux module, 20 Channels, 100GHz spaced, Starting ITU Channel 40, end ITU Channel 59, with OTDR port, Express port, Tx and Rx monitoring ports, in F cassette with SC/APC connectors (Test Ports Only)
GW-OP-MDM4-20-23-CLA	Gigawave 4ch DWDM module, 1st ch 20, 4th ch 23, Tx Rx monitor , exp and UPG ports, cassette (89x51x8mm), SMF-28 Ultra , 900um jacket , 1m fiber length, LC/APC connectors
GW-OP-MDM4-56-59-CLA	Gigawave 4ch DWDM module, 1st ch 56, 4th ch 59, Tx Rx monitor , exp and UPG ports, cassette (89x51x8mm), SMF-28 Ultra , 900um jacket , 1m fiber length, LC/APC connectors
GW-OP-MDM8-20-27-CLA	Gigawave 8ch DWDM module, 1st ch 20, 8th ch 27, Tx Rx monitor , exp and UPG ports, cassette (96x78x8mm), SMF-28 Ultra , 900um jacket , 1m fiber length, LC/APC connectors
GW-OP-MDM8-52-59-CLA	Gigawave 8ch DWDM module, 1st ch 52, 8th ch 59, Tx Rx monitor , exp and UPG ports, cassette (96x78x8mm), SMF-28 Ultra , 900um jacket , 1m fiber length, LC/APC connectors
GW-OP-OADM2-51-27-LGX1	Gigawave 2 Channel 100GHz Add/Drop module, CH27, CH51, 2×4 configuration in LGX box. LC/APC
GW-OP-OADM2-51-27-CLA	Gigawave 2 Channel 100GHz Add/Drop module, CH27, CH51, 2×4 configuration in F size cassette, LC/APC
GW-OP-OADM2-52-28-LGX1	Gigawave 2 Channel 100GHz Add/Drop module, CH28, CH52, 2×4 configuration in LGX box, LC/APC
GW-OP-OADM2-52-28-CLA	Gigawave 2 Channel 100GHz Add/Drop module, CH28, CH52, 2×4 configuration in F size cassette, LC/APC
GW-OP-OADM4-51-52-27-28-CLA	Gigawave 4 Channel 100GHz Add/Drop module, CH52, CH51, CH28, CH27, 2×4 configuration in F size cassette, LC/APC
GW-OP-OADM4-61-62-35-36-CLA	Gigawave 4 Channel 100GHz Add/Drop module, CH62, CH61, CH36, CH35, 2×4 configuration in F size cassette, LC/APC
GW-OP-BMDM5-20-59-FALA	Gigawave 5 port band pass filter Mux-Demux covering CH20 to CH59 with Tx Rx monitor , exp in FOSC A tray, SMF-28 Ultra , 900um jacket , 1m fiber length, LC/APC connector on all port
GW-OP-BMDM10-20-59-FALA	Gigawave 10 port band pass filter Mux-Demux covering CH20 to CH59 with Tx Rx monitor , exp in FOSC A tray, SMF-28 Ultra , 900um jacket , 1m fiber length, LC/APC connector on all port
GW-OP-RB-SA	Gigawave Red (ITU18-37) / blue (ITU 42-61) filter; tube, SC/APC
GW-OP-OTDR-LA	Gigawave WDM, OTDR filter; tube, 3xLC/APC

Data Sheet: GigaWave Optical Passive Modules (ANW2046)

GigaWave Optical Passives

Benefits

Features

Related Content

GigaXtend GS7 1.8GHz Node

Distributed Access Architecture (DAA)

The 2050 Project

GigaWave Optical Passives, 20/40/48-Channel
Multiplexer/Demultiplexer

GigaWave Optical Passives, 4- or 8-Channel Multiplexer/Demultiplexer

GigaWave Optical Passives, 2- or 4-Channel Optical

GigaWave Optical Passives, 1×5 or 1×10 Ports Band Multiplexer/Demultiplexer

GigaWave Optical Passives, – Red/Blue OTDR Filter

Stay connected! Subscribe to receive updates:

GigaWave Optical Passives

Benefits

Features

Related Content

GigaXtend GS7 1.8GHz Node

Distributed Access Architecture (DAA)

The 2050 Project

GigaWave Optical Passives, 20/40/48-Channel Multiplexer/Demultiplexer

GigaWave Optical Passives, 4- or 8-Channel Multiplexer/Demultiplexer

GigaWave Optical Passives, 2- or 4-Channel Optical

GigaWave Optical Passives, 1×5 or 1×10 Ports Band Multiplexer/Demultiplexer

GigaWave Optical Passives, – Red/Blue OTDR Filter

Stay connected! Subscribe to receive updates:

Privacy settings

With the slider, you can enable or disable different types of cookies:

This website will:

This website won't:

This website will:

This website won't:

This website will:

This website won't:

This website will:

This website won't:

GigaWave Optical Passives, 20/40/48-Channel
Multiplexer/Demultiplexer
