XDS-PRO1R Audio Digital Media Receiver

The XDS-PRO1R digital audio receiver allows radio stations to receive audio broadcasts from distributed satellite or IP networks for live broadcasting or storage for later play-out. The unit provides targeted advertising capabilities, allowing radio networks to play localized ads and other content relevant to specific locations. In addition to copy splitting, the cost-effective XDS-PRO1 supports audio insertion and digital live recording with playback to delay time zone feeds. It also has advanced station automation interfaces via IP, RS-232, relay closures, OPTOs and commands to seamlessly interface with automation systems. Its advanced scheduling capabilities allow networks and stations to automatically switch between live & pre-recorded channels and programs.

Request Info How To Buy
  • XDS-PRO1R Audio Digital Media Receiver
Data Sheet: XDS-PRO1R
Brochure: XDS Radio Platform
White Paper: Revolutionizing Audio Distribution, Management and Monitoring
Solution: End-to-End Audio Distribution

Features

  • Low bitrate down to 100 Ksps (optional), 256 Ksps standard
  • Can fit in a 150 kHz carrier (optional), 400 kHz standard
  • DVB S/S2 – QPSK/8PSK
  • MPEG-2, AAC-LC,HEv1,and HEv2
  • One balanced analog output
  • One digital AES/EBU output
  • One IP AES67 output (one stream)
  • 128 GB M2SATA solid-state drive
  • Store and forward file delivery
  • Receives live IP streams
  • Locally input LIDs, liners and spots
  • Import/export content locally
  • Store and forward
  • Audio input for network automation
  • One PAD output port for RDS
  • 16 relay closures (hard, RS-232, and IP)
  • Program station automation via Web UI
  • Two 100BaseT Ethernet ports with VLAN
  • DHCP, NFS, HTTP and Telnet
  • Alarms via relay closure, email and SNMP
  • In-field firmware upgradable
  • Record and insertion of media
  • Remote control via Xpress or XDSv7
  • For satellite or streaming networks
  • Cost-effective

Solution: Audio Content Management & Distribution


Revolutionizing Audio Distribution, Management and Monitoring

Everything you need to know to build the ultimate audio distribution and content management system for your radio network

DOWNLOAD WHITE PAPER

Brochure

Read more about the XDS Radio Platform, the most innovative, advanced, cost-effective radio & audio broadcasting platform.

Learn More
End-to-End Radio Solution

Control content distribution and monetization for radio networks with a unified and integrated solution that can be managed from anywhere in the world.

Learn More
Blog

Why network operators require a next-gen approach to distribution & content management

Learn More
RF Input
Frequency Range 950 to 2150 MHz
Data Rates 256 Ksps to 40 Msps (DVB-S)
1 Msps to 40 Msps (DVB-S2)
100 Ksps (Optional)
Carrier Level -20 to -60 dBm
Connector F-type Female
Impedance 75 Ω
Inb DC Power +18 VDC @ 500 mA
Modulation QPSK (DVB-S) / 8PSK (DVB-S2)
FEC Per DVB-S/DVB-S2
IP Interfaces
LAN 10/100 BaseT RJ45
Control Interfaces
Network Management Via Satellite or TCP/IP
Web HTTP, Telnet on 10/100 BaseT RJ45
Serial Console RS232C,DB9-F
Input Ports
Audio 1 Balanced (600 Ω) DB9-F
1 AES/EBU DB9-F
OPTO 4 Form A DB9-F
Output Ports
Audio 1 Balanced output (600 Ω) DB9-M
1 Digital DB9-AES/EBU
1 Digital IP-AES 67 (Livewire+)
PAD RS232C DB9-F
Relays 16 Form A, NO, DB37-F
Audio Decoders MPEG-1 Layer II and AAC LC
Status alarm out
Mechanical & Environmental
Input Voltage 90 – 240 VAC (50/60 Hz)
Power Consumption 150 W Maximum
Dimensions 3.5″ (H) x 18″ (W) x 12″ (D)
Mounting 19″, 2RU
Weight 8 lbs.
Operating Temperature 0°C to 50°C
Part Number Description
XDS-PRO1R Audio Digital Media Receiver
XDS-LBR Low-Bitrate 100-Ksps Module
XDS-AMR-MOD AM/FM/HD Receiver Module

Data Sheet: XDS-PRO1R Audio Digital Media Receiver (ANW1268)

Brochure: XDS Radio Platform (ANW1380)
